Technical data
PI 300 D
PI 300 DN
PE 300 DC9
Measurement board
Pirani
measurement
boards
Pirani
Measurement
Boards
Cold Cathode
Measurement
Board
Number of measuring circuits
2
2
2
For gauge
TP R 010, TP R 018 TPR 017
IKR 050
Weig ht
0.14 kg
0.14 kg
0.26 kg
Measurement range max.
100 0 mba r
10 00 mba r
5·10
-3
mbar
Measurement range min.
8·10
-4
mbar 8·10
-4
mbar 1·10
-9
mbar
Sensor cable length
100 m
10 0 m
100 m
Reaction time of the output signal: Decay
600 ms*
600 ms*
Reaction time of the output signal: Rise
50 ms*
50 ms*
16 ms
*At sudden pressure change: - Rise (10-90 %) from <10
-3
to 1000 mbar
- Decay (90-10 %) from 1000 to <10
-3
mbar
Ordering Number
Measurement Boards
PT 546 920-T PT 549 214-T PT 441 375-T
Technical data
CP 300 C9
CP 300 C10 CP 300 T11
Measurement board
Pirani/cold
cathode measure-
ment board
Pirani/Cold
Cathode Measure-
ment Board
Pirani/cold
cathode measure-
ment board
Number of measuring circuits
1 each
1 each
1 each
For gauge
TP R 010 , T PR 018,
IKR 050
TPR 010, TPR 018,
IKR 060
TPR 010, TPR 018,
IKR 070
Weig ht
0.21 kg
0.23 kg
0.25 kg
Measurement range max.
100 0 mba r
10 00 mba r
1000 mbar
Measurement range min.
5·10
-9
mbar 1·10
-10
mbar 1·10
-11
mbar
Sensor cable length
100 m
10 0 m
100 m
Reaction time of the output signal: Rise
10 ms *
50 ms*
50 ms*
*Sudden pressure changes: - Rise (10-90 %) from <10
-9
to <10
-3
to mbar
Ordering Number
Measurement Boards
PT 441 000-T PT 441 114-T PT 441 080-T
